  • Advanced "Top Volant" System – Ensures easy to use dough formation.
  • Designed for Mini Sandwiches & Baguettes – Ideal for uniform moulding.
  • Universal Compatibility – Works seamlessly with all ovens and bakery equipment.
  • Compact & Space-Saving – Efficient design requiring minimal floor space.
  • "Flexi Layer" Pressure Boards – Exclusive Ondermak technology for optimal shaping.
  • Integrated Flour Duster Unit – Ensures consistent flour distribution.
  •  Integrated Dough Centralizer – Optimal dough dropping position
  • Bolted Joints -  for easy pressure board replacement.
  • 1 x Önder® pressure board
  • Non-stick rollers (2x) with front and back scrapers
  • Dough-friendly conveyor belt
  • Folding dough collector stand
  • Enhanced Mobility - Swivel wheels with brakes
  • Safety – Front-back  hand protection shields, free release
  •  Stainless Steel Build – Structure and legs
  • User-Friendly Controls – Analog control
  • Easy Maintenance – Quick cleaning and low upkeep.
  • CE-certified
  • 2-year warranty



Technical Specifications

Kapasite / Capacity / Capacidad

Adet/sa. - Pcs/hr.

1800

 Şekil Verme Aralığı / Dough Range / Rango De Masa

 gr.

50-200

Yastık Sayısı / Pressure Board Nr. / Nr. Tablero

 Nr.

1

 Genişlik (W) / Width / Ancho

  mm

640

 Uzunluk (L) / Length / Largo

  mm

1595 +  430

Yükseklik (H) / Height / Alto

  mm

1125

Hamur Giriş Yüksekliği (H1) / Dough Input / Masa Entrada

 mm

1054

Hamur Çıkış Yüksekliği (H2) / Dough Output / Masa Salida

  mm

870

Elektrik Gücü / Electric Power / Energía

  Kw

   1.1

 Elektrik Bağlantı / Electric Connection / Conexión Electrica

 Volt-Vac/Hz

 380v/50-60hz 3 Phase

Ağırlık / Weigth / Peso

  Kg

175

Merdane Ayari / Roller Adjustment / Ajusto Rodillo

 mm

  0-25

 Ekmek Uzunluğu / Max. Form Length / Max. Largo Formacion

 mm

400

 Taşıma Bandı Genişliği / Conveyor Belt Width / Ancho Cinta

 mm

420

Taşıma Bandı Boyu / Conveyor Belt Length / Largo Cinta

 mm

3080

Unlama Ünitesi / Flour Duster / Harinadora

 -

 Var/Yes/Si

Materyal / Material

 Paslanmaz

 Stainless Stell/Inox

  Un Toplama Tepsisi/Flour Recyle Tray/Bandeja Harina Reciclo



 Var/Yes/Si
